华和HH50Z-N6-D

华和HH50Z-N6-D
产品型号:HH50Z-N6-D
货叉尺寸:1220× 150× 50mm
总 长:3480mm
总 长:3480mm
起升速度:600mm/s
违禁词爬坡度:20%
自重:8550Kg



产品特点

华和HH50Z-N6-D



1型号UNITHH50 (Z)HH50 (Z)HH60(Z)HH60 (Z)HH70 (Z)HH70 (Z)
2动力形式Diesel 柴油Diesel 柴油Diesel 柴油Diesel 柴油Diesel 柴油Diesel 柴油
3额定载荷kg500050006000600070007000
4载荷中心距mm600600600600600600

5起升高度mm300030003000300030003000
6自由起升高度mm150150150150150150
7货叉尺寸mm1220×150×501220×150×501220×150×601220×150×601220×150×701220×150×70
8货叉间距(外侧)mm300/1200300/1200300/1200300/1200300/1200300/1200
9门架倾角(前/后)deg6/126/126/126/126/126/12
10前悬距mm590590590590590590
11外形尺寸总长不带货叉mm348034803530353035803580
12带货叉mm348034803530353035803580
13车轮宽mm200020002000200020002000
14门架不起升高度mm262526252625262526252625
15门架起升高度mm442044204420442044204420
16安全架高度mm225022502250225022502250
17最小转弯半径mm337033703370337033703370
18最小直角通道宽度mm375537553755375537553755

19行驶速度(空载/满载)km/h13/1213/1213/1213/1213/1213/12
20起升速度(空载/满载)mm/s600/400600/400600/400600/400600/400600/400
21违禁词爬坡度%202020202020



22轮胎前轮8.25-15-14PR8.25-15-14PR8.25-15-14PR8.25-15-14PR8.25-15-14PR8.25-15-14PR
23后轮8.25-15-14PR8.25-15-14PR8.25-15-14PR8.25-15-14PR8.25-15-14PR8.25-15-14PR
24轮距前轮mm147014701470147014701470
25后轮mm170017001700170017001700
26轴距mm225022502250225022502250
27最小离地间隙 (空载/满载)Mast 门架mm174/145174/145174/145174/145174/145174/145
28Frame 车架mm190/180190/180190/180190/180190/1880190/1880
29蓄电池v/ah2×12/902×12/902×12/902×12/902×12/902×12/90
30发动机Model 型号6BG1CY61026BG1CY61026BG1CY6102
31Rated output 额定功率kw/r.p.m82/200081/250082/200081/250082/200081/2500
32Rated torque 额定扭矩n.m/r.p.m411/1600353/1650411/1600353/1650411/1600353/1650
33排量cc649457856494578564945785
34缸数666666
35缸径×行程mm105×125102×118105×125102×118105×125102×118
36双变型号HydraulicHydraulicHydraulicHydraulicHydraulicHydraulic
37档位(前/后)2/12/12/12/12/12/1
38工作压力mpa181818181818
